2-20 Preparations
• To reduce induced electrical noise, the leads on the temperature controller’s
terminal block must be wired separately from large-voltage/large-current
power leads. Also, avoid wiring leads in parallel with power leads or in the
same wiring path. Other methods such as separating conduits and wiring
ducts, or using shield wire are also effective and recommended.
Wiring Control Output 1
The following diagrams show the available outputs and their internal
equalizing circuits.
Figure 2.19
900-TC16 Control Output 1
1
2
1
2
L
+
−
GND
+V
+
−
−
1
2
+
+V
L
Relay Voltage (SSR) Analog Current
L
+
v
+
−
900-TC8 Control Output 1
Relay Voltage (SSR) Analog Current
+
v
L
+
−
GND
+
v
L
+
−
900-TC32 Control Output 1
