Rockwell Automation Allen-Bradley PowerFlex 700S Programming Manual

Rockwell Automation Publication 20D-PM001D-EN-P - March 2019 199
Appendix D
PowerFlex 700S Permanent Magnet Motor
Specifications
Compatible Permanent
Magnet Motors
The following table contains a list of specifications for the permanent magnet
motors compatible with PowerFlex® 700S drives. Note that you must have a high
resolution Stegmann or Heidenhain encoder or compatible resolver.
Table 9 - Motor Name Plate and Rating Specifications
Parameter No. 1 2 3 4 5 7
Model Number Motor NP Volts
(line to line V rms)
Motor NP FLA
(A rms)
Motor NP
Frequency
(Hz)
Motor NP RPM
(oper. rpm)
Motor NP
Power (KW)
Motor
Poles
Current peak
(A rms)
System Cont. Stall
Torque (N•m)
Motor Max
RPM
(rpm)
MPM-A1151M 240 4.2 333.3 5000 0.90 8 21.6 2.18 6000
MPM-A1152F 240 5.9 266.7 4000 1.40 8 31.7 4.74 5000
MPM-A1302F 240 7.4 266.7 4000 1.65 8 35.6 5.99 4500
MPM-A1304F 240 8.1 233.3 3500 2.20 8 34.2 9.30 4000
MPM-A1651F 240 14.5 200.0 3000 2.50 8 52.2 10.70 5000
MPM-A1652F 240 18.1 233.3 3500 4.03 8 73.0 13.50 4000
MPM-A1653F 240 23.2 200.0 3000 5.10 8 84.3 18.60 4000
MPM-A2152F 240 33.7 133.3 2000 5.20 8 89.0 27.00 4000
MPM-A2153F 240 32.8 133.3 2000 5.80 8 85.2 34.00 4600
MPM-A2154C 240 24.8 116.7 1750 6.50 8 89.8 55.00 2000
MPM-A2154E 240 29.6 133.3 2000 7.00 8 90.7 44.00 2650
MPM-B1151F 480 1.5 266.7 4000 0.75 8 7.0 2.18 5000
MPM-B1151T 480 3.1 333.3 5000 0.90 8 14.5 2.18 7000
MPM-B1152C 480 2.3 166.7 2500 1.20 8 8.8 2.18 3000
MPM-B1152F 480 2.9 266.7 4000 1.40 8 15.5 4.74 5200
MPM-B1152T 480 5.2 266.7 4000 1.40 8 26.8 4.74 7000
MPM-B1153E 480 2.7 200.0 3000 1.40 8 15.3 6.55 3500
MPM-B1153F 480 3.2 266.7 4000 1.45 8 22.6 6.55 5500
MPM-B1153T 480 5.5 266.7 4000 1.45 8 39.2 6.55 7000
MPM-B1302F 480 3.4 266.7 4000 1.65 8 15.6 5.99 4500
MPM-B1302M 480 5.0 266.7 4000 1.65 8 22.6 5.99 6000
MPM-B1302T 480 6.6 266.7 4000 1.65 8 30.7 5.99 7000
MPM-B1304C 480 3.4 183.3 2750 2.00 8 15.8 10.20 2750
MPM-B1304E 480 4.1 166.7 2500 2.20 8 24.2 10.20 4000
MPM-B1304M 480 7.3 233.3 3500 2.20 8 42.9 10.20 6000
MPM-B1651C 480 4.7 200.0 3000 2.50 8 20.6 10.70 3500
MPM-B1651F 480 8.2 200.0 3000 2.50 8 36.0 10.70 5000
MPM-B1651M 480 10.9 200.0 3000 2.50 8 40.2 10.70 5000
MPM-B1652C 480 7.0 166.7 2500 3.80 8 23.8 16.00 2500
MPM-B1652E 480 8.0 233.3 3500 4.30 8 42.8 19.40 3500
MPM-B1652F 480 11.0 233.3 3500 4.30 8 59.5 19.40 4500
MPM-B1653C 480 10.5 133.3 2000 4.60 8 41.9 26.80 2500
MPM-B1653E 480 10.2 200.0 3000 5.10 8 51.6 26.80 3500
MPM-B1653F 480 13.2 200.0 3000 5.10 8 66.7 26.80 4000
