Rockwell Automation PowerFlex 7000 Technical Data

2-228 Parameters Listed by Linear Number
7000-TD002A-EN-P – September 2007
Name Min. Max. Default Units
Read-
Only
Access
589 LineNeutral Volt -2.000 2.000 - pu Y Basic
590 Rec Gating Test - - Off N Service
591 Inv Gating Test - - Off N Service
592 XIO Standard IO - - Card # 1 N Advanced
593 XIO Ext Faults - - Unassigned N Advanced
594 XIO Config Errs - - - Y Advanced
596 XIO Adaptr Loss - - - Y Service
597 Parameter Error 0 65535 - Y Basic
608 Inv DvcDiag FbkA 0 65535 - Y Service
609 Inv DvcDiag FbkB 0 65535 - Y Service
610 Master VoltUnbal 0.00 1.00 - Y Service
611 Slave1 VoltUnbal 0.00 1.00 - Y Service
612 Slave2 VoltUnbal 0.00 1.00 - Y Service
613 Master Cur Unbal 0.00 1.00 - Y Service
614 Slave1 Cur Unbal 0.00 1.00 - Y Service
615 Slave2 Cur Unbal 0.00 1.00 - Y Service
616 Slave1 Angle -360.0 360.0 - deg Y Service
617 Slave2 Angle -360.0 360.0 - deg Y Service
618 Inv DvcDiag FbkC 0 65535 - Y Service
619 Motor Flux Unbal 0.00 1.00 - Y Service
620 Rec DvcGat SeqnA 0 65535 - Y Service
621 Rec DvcGat SeqnB 0 65535 - Y Service
623 Flux Cmd Limit 0.000 1.500 - pu Y Service
624 Line Reactor 0.00 50.00 0.00 mH N Service
625 Line Reactor pu 0.00 1.00 - pu Y Service
626 Rec DvcGat SeqnC 0 65535 - Y Service
627 Rec DvcDiag FbkA 0 65535 - Y Service
628 Rec DvcDiag FbkB 0 65535 - Y Service
629 Rec DvcDiag FbkC 0 65535 - Y Service
630 Speed Pot Vmin -10.00 10.00 0.00 V N Service
631 Speed Pot Vmax -10.00 10.00 10.00 V N Service
632 Anlg Inp1 Vmin -10.00 10.00 0.00 V N Service
633 Anlg Inp1 Vmax -10.00 10.00 10.00 V N Service
634 Anlg Inp2 Vmin -10.00 10.00 0.00 V N Service
635 Angl Inp2 Vmax -10.00 10.00 10.00 V N Service
636 Anlg Inp3 Vmin -10.00 10.00 0.00 V N Service
637 Anlg Inp3 Vmax -10.00 10.00 10.00 V N Service
638 Forced Flt Mask - - 11111111 N Basic
639 Forced Flt Owner - - - Y Monitor
640 Idc Fac 7p to 5p 0.00 2.00 1.00 N Service
641 TrqCmd0 Tach 0.00 4.00 0.00 N Service
642 InvControl Flag2 - - - Y Service
643 Inv DCLink Volt -2.000 2.000 - pu Y Service
644 Encoder Offset 0 360 0 deg N Advanced
645 Rec DCLink Volt -2.000 2.000 - pu Y Service
646 Drive Warning2 - - - Y Service
647 Drv Wrn2 Mask - - 1111111111111111 N Basic
648 Drive VSB Gain 0.0 6553.5 - V/V Y Service
649 Drive VSB Tap - - - Y Service
650 Ext Fault PLC - - 0000000000000000 N Service
651 Ext Fault Selct - - 0000000000000000 N Basic
652 Anlg Inp Config - - 0000000000000001 N Service
653 IsoTx AirFlow -10.0 10.0 - V Y Basic
654 IsoTx AirFlowTrp 0.0 10.0 2.5 V N Service
655 IsoTx AirFlowWrn 0.0 10.0 3.0 V N Service
656 IsoTx AirFlowNom 0.0 10.0 3.6 V N Service
