RODEC
MX300 MKIII
2
TABLE OF CONTENTS
- Specifications - 2 -
- Safety instructions - 3 -
- Installation of the mixing panel - 3 -
- Frontpanel, switches and control - 3 -
- Connections - 5 -
- Operating instructions - 6 -
- Subsonic filter - 7 -
- Pictures on cover - 27 -
SPECIFICATIONS
Inputs Input sensitivity Signal/Noise Ratio Remarks
PHONO 1-7
AUX A 1-7
AUX B 1-7
MIC 1-7 symm.
MIC DJ symm.
assym.
2.3mV/50kΩ
220mV/50kΩ
220mV/50kΩ
4.0mV/4kΩ
0.7mV/1.2kΩ
0.5mV/22kΩ
< -80dB
< -92dB
< -92dB
< -83dB
< -85dB
< -89dB
RIAA correction
Outputs
Master 1 symm.
Master 2 assymm.
Master 2 symm.
Monitor assym.
Recording 1-8
Phones
3.3V/600Ω
1.55V/10kΩ
3.3V/600Ω
1.55V/10kΩ
500mV/10kΩ
12V/600Ω
Subsonic filter
Subsonic filter
Subsonic filter
Subsonic filter
Recording out selector
Phones 200-600Ω
- Tone controls: Bass +/-13dB @ 100Hz
Mid +/-13dB @ 1kHz
High +/-13dB @ 10kHz
- Subsonic filter: -25dB @ 10Hz
- Power source: Standard: 230V / 50Hz-60Hz
on request: 100V-117V / 50Hz-60Hz
- Fuse: T500mA
- Power consumption: OFF=2.0VA ON=48.8VA
- Approbation: CE-approved
- Dimensions: Front: 482mm x 310mm (19” x 7HE)
Chassis: 444mm x 295mm x 150mm
- Weight: 7.6kg
DESIGN AND SPECIFICATIONS ARE SUBJECT TO CHANGE WITHOUT PRIOR NOTICE.
MODEL MX300MKIII
SERIAL NUMBER …………………………… (on the back of the set)
Please give model and serial number when info is requested.
Thank you for purchasing the RODEC mixing panel MX300MKIII.
This mixing panel is a topline product, capable of outstanding performance in combination with high
quality systems.
