PRT-LT Series Readers fv1.25 Rev. G 2016-10-08
Page 2 from 17
1. I MPORTANT N OTES
The PRT-LT reader can be configured for several data output format however the factory shipped
new unit is pre-configured for RACS address ID=0. If required reader can be reconfigured
manually using Memory Reset procedure. Comparing with PRT-EM series access terminals the PRT-
LT series readers doesn’t support standalone operating mode.
Note: If after power up the LED SYSTEM is lit and accompanied with repeated sound it means
that contents of reader’s memory is corrupted. In this case reader must be initialized and
configured from the scratch.
1.1. COMPATIBILITY RULES
Always check the firmware and hardware version for which manual is dedicated. Using wrong
version of manual may cause that device will not behave as described in document.
1.2. ABOUT THIS MANUAL
This manual is dedicated for all versions of PRT-LT readers: with keypad and without keypad. No
matter if the PRT-LT readers have built-in keypad or not they represents the same logical
functionality. The only difference between various types of PRT-LT readers is limited to their
mechanical construction, environment in which they can be installed and keypad which exist in
some PRT-LT units.
2. G ENERAL D ESCRIPTION
The PRT-LT readers have been designed for use in access control installations to enable user
identification via EM 125 KHz (and compatible) proximity cards and/or PIN-s. The PRT-LT reader
works as a slave unit serving a sole purpose of reading cards/PIN-s then providing subsequent
transmission of such collected data to host ACU for further processing. Reader offers several data
transmission formats including popular Wiegand/Magstripe data protocols.
2.1. FEATURES
2.1.1. General
· EM 125 KHz proximity cards (EM4100/4102 compatible)
· Up to 10..15 cm reading range (*)
· Outdoor and indoor installations (*)
· 26/32/32 reversed/34/42/66 bit Wiegand data formats
· Magstripe data format (ABA Track II emulation)
· RACS data output format (Roger format)
· Various options for transmission of PIN-s and keys
· LED control input
· BUZZER control input
· Tamper switch
· CE approval
(*) – depends on individual reader type
2.2. PROXIMITY CARDS
The PRT-LT was designed for EM 125 KHz proximity cards compatible with EM 4100/4102
transponders. Reader returns card number without check sum bits. Card number is transmitted
starting from the LSB to MSB and if required (it depends on the data output format selected for the
given reader) can be supplemented with leading zeros or reduced on the MSB positions.
2.3. FUNCTION KEYS
Some of the PRT-LT readers are equipped with two (e.g. PRT12LT) or one (PRT42LT and PRT42LT-
BK) function keys: [F1]- marked with door bell icon and [F2] – marked with the light bulb icon. The
function of each function keys depends on the reader’s operation mode.
