16
CHECK GAP BETWEEN
ROLLER AND WALL (9/32 in.)
BRAKE CALIPER
MOUNTING BRACKET
SECTION B
SCALE 1/10
OUTER POSITIONING SPACER
SPACERS PREVENT FRONT ROLLER SIDE
MOVEMENT DURING SHIPPING AND INSTALLING
BRAKE CALIPER ASSEMBLY
SHOULD FLOAT IN MOUNTING BRACKET
WHEN AT MINIMUM RESISTANCE
CHECK FOR SIDE TO SIDE MOVEMENT TO
AVOID RUBBING AGAINST ROTOR
