R&S
®
CMW 500 GPRF Applications
GPRF Measurements and Generators
Operating Manual 1202.3986.32 – 03 140
Table View
The results in the bar graphs of the Diagram View is also displayed in a table with
numeric values.
Power measurement results: Table View
7.1.3 External Power Sensor Measurement
The External Power Sensor measurement records the power values measured by an
external R&S NRP power sensor and performs a statistical evaluation.
Sensor connection and test setup
Measurement settings
Zeroing
Measurement results
7.1.3.1 Sensor Connection and Test Setup
The external power sensor is connected to the SENSOR connector at the front panel
of the R&S CMW 500. If the sensor measures an external signal, no extra RF
connection with the R&S CMW 500 is needed.
