Rohde & Schwarz CMW 500 - Generating a CW Signal; Generating a Dual-Tone Signal

R&S
®
CMW 500 GPRF Applications
GPRF Programming
Operating Manual 1202.3986.32 – 03 165
7.3.1.2 Generating a CW Signal
FPRINT ************************************************************
FPRINT System-Reset
FPRINT ************************************************************
*RST;*OPC?
*CLS; *OPC?
FPRINT ************************************************************
FPRINT Route output signal, define external attenuation
FPRINT ************************************************************
ROUTe:GPRF:GENerator:RFSettings:CONNector RF1C
SOURce:GPRF:GENerator:RFSettings:EATTenuation 2
FPRINT ************************************************************
FPRINT Set frequency and level, activate CW mode
FPRINT ************************************************************
SOURce:GPRF:GENerator:RFSettings:FREQuency 1.000000E+009
SOURce:GPRF:GENerator:RFSettings:LEVel -70
SOURce:GPRF:GENerator:BBMode CW
FPRINT ************************************************************
FPRINT Switch on generator. With command synchronization, the queried
FPRINT generator state is "ON".
FPRINT ************************************************************
SOURce:GPRF:GENerator:STATe ON; *OPC?
SOURce:GPRF:GENerator:STATe?
7.3.1.3 Generating a Dual-Tone Signal
FPRINT ************************************************************
FPRINT System-Reset
FPRINT ************************************************************
*RST;*OPC?
FPRINT ************************************************************
FPRINT Activate dual-tone mode, set frequencies and levels
FPRINT ************************************************************
SOURce:GPRF:GENerator:BBMode DTON
SOURce:GPRF:GENerator:RFSettings:FREQuency 1.000000E+009
SOURce:GPRF:GENerator:DTONe:OFRequency1 1000
SOURce:GPRF:GENerator:DTONe:OFRequency2 2000
SOURce:GPRF:GENerator:DTONe:Ratio 10
