Rohde & Schwarz CMW 500 - Using the Generator List Mode

R&S
®
CMW 500 GPRF Applications
GPRF Programming
Operating Manual 1202.3986.32 – 03 166
FPRINT ************************************************************
FPRINT Query levels of source 1 and source 2
FPRINT ************************************************************
SOURce:GPRF:GENerator:DTONe:LEVel1?
SOURce:GPRF:GENerator:DTONe:LEVel2?
FPRINT ************************************************************
FPRINT Switch on generator
FPRINT ************************************************************
SOURce:GPRF:GENerator:STATe ON; *OPC?
7.3.1.4 Using the Generator List Mode
FPRINT ************************************************************
FPRINT System-Reset
FPRINT ************************************************************
*RST;*OPC?
FPRINT ************************************************************
FPRINT Activate list mode, set frequencies and levels for 5 steps
FPRINT ************************************************************
SOURce:GPRF:GENerator:LIST ON
SOURce:GPRF:GENerator:LIST:SSTop 0, 4
SOURce:GPRF:GENerator:LIST:FREQuency 0, 1.9224E+009
SOURce:GPRF:GENerator:LIST:FREQuency 1, 1.9224E+009
SOURce:GPRF:GENerator:LIST:FREQuency 2, 1.9224E+009
SOURce:GPRF:GENerator:LIST:FREQuency 3, 1.9224E+009
SOURce:GPRF:GENerator:LIST:FREQuency 4, 1.9224E+009
SOURce:GPRF:GENerator:LIST:RFLevel 0, -20
SOURce:GPRF:GENerator:LIST:RFLevel 1, -23
SOURce:GPRF:GENerator:LIST:RFLevel 2, -26
SOURce:GPRF:GENerator:LIST:RFLevel 3, -29
SOURce:GPRF:GENerator:LIST:RFLevel 4, -32
SOURce:GPRF:GENerator:LIST:DGAin 0, -2
SOURce:GPRF:GENerator:LIST:DGAin 1, -2
SOURce:GPRF:GENerator:LIST:DGAin 2, -2
SOURce:GPRF:GENerator:LIST:DGAin 3, -2
SOURce:GPRF:GENerator:LIST:DGAin 4, -2
FPRINT ************************************************************
FPRINT Set dwell time equal to the duration of a WCDMA slot,
