R&S
®
CMW 500 GPRF Applications
GPRF Command Reference
Operating Manual 1202.3986.32 – 03 175
<Frequency> Range: 70 MHz to 3300 MHz (increment 0.1 Hz)
Def. value 900.000 MHz
Def. unit: Hz
Example See Specifying General Measurement Settings
Characteristics Firmware version V1.00
7.4.2 GPRF Generator Commands
The commands of the General Purpose RF generator are divided into the groups listed
below. For an overview of the commands refer to Command Groups.
Generator Control and States
Signal Routing
Constant-Frequency Settings
Baseband Settings
List Mode Settings
Issues of special interest for all commands:
GEN<i> Abbreviation of "GENerator<instance>". For better readability only the
abbreviated form (which is also accepted by the instrument) is given in
the command reference.
It is possible to use up to four instances of the same firmware
application in parallel.
For further information refer to Firmware Applications.
7.4.2.1 Command Groups (RF Generator)
Generator Control and States Page
SOURce:GPRF:GEN<i>:STATe...............................................................................................................176
Signal Routing Page
ROUTe:GPRF:GEN<i>:RFSettings:CONNector .......................................................................................177
SOURce:GPRF:GEN<i>:RFSettings:EATTenuation .................................................................................177
Constant-Frequency Settings Page
SOURce:GPRF:GEN<i>:RFSettings:FREQuency ....................................................................................177
SOURce:GPRF:GEN<i>:RFSettings:LEVel ..............................................................................................177
Baseband Settings Page
SOURce:GPRF:GEN<i>:BBMode ............................................................................................................178
SOURce:GPRF:GEN<i>:DTONe:OFRequency<source>..........................................................................178
