R&S
®
CMW 500 GPRF Applications
GPRF Command Reference
Operating Manual 1202.3986.32 – 03 179
<Ratio> Range: –0.00 dB to +30.00 dB (increment 0.01 dB)
Def. value: 0.00 dB
Def. unit: dB
Example See Generating a Dual-Tone Signal
Characteristics Firmware version V1.00
SOURce:GPRF:GEN<i>:DTONe:LEVel<source>? <Level (RMS)>
Queries the output level of the source signal <source>. The output level is a function of
the generator output level (SOURce:GPRF:GEN<i>:RFSettings:LEVel) and the
ratio SOURce:GPRF:GEN<i>:DTONe:RATio.
<source> No. of source signal (1 or 2)
<Level (RMS)> Range: –143 dBm to +10 dBm at RF 1 COM and RF 2 COM, –
135 dBm to +18 dBm at RF 1 OUT (increment 0.01 dB); please
also notice the ranges quoted in the "Specifications"
Def. value: –80.00 dBm
Def. unit: dBm
Example See Generating a Dual-Tone Signal
Characteristics Firmware version V1.00
SCPI: Query only
SOURce:GPRF:GEN<i>:ARB:FILE '<File Name>'
Selects a waveform file, to be used for the arbitrary waveform generator
(SOURce:GPRF:GEN<i>:BBMode ARB).
'<File Name>' String parameter, specifies the name of the waveform file (.wv).
Characteristics Fi
rmware version V1.00
7.4.2.6 List Mode Settings
The following commands configure the list mode of the RF generator.
SOURce:GPRF:GEN<i>:LIST <Enable>
Enables or disables the list mode of the RF generator.
<Mode> Sequence Mode
OFF: List mode disabled (constant-frequency generator)
ON: List mode enabled
Def. value: OFF
Example See Using the Generator List Mode
