Rohde & Schwarz CMW 500 - Trigger Settings

R&S
®
CMW 500 GPRF Applications
GPRF Command Reference
Operating Manual 1202.3986.32 – 03 188
CONFigure:GPRF:MEAS<i>:POWer:FILTer:TYPE <Filter>
Selects the IF filter type.
<Filter> GAUSs: Filter of Gaussian shape with selectable bandwidth
(CONFigure:GPRF:MEAS<i>:POWer:FILTer:GAUSs:BWIDt
h)
BANDpass: Bandpass filter with selectable bandwidth
(CONFigure:GPRF:MEAS<i>:POWer:FILTer:BANDpas:BWI
Dth)
WCDMA: 3.84 MHz RRC filter with a roll-off = 0.22 for WCDMA
TX tests
CDMA: 1.4 MHz-wide baseband receiver filter for CDMA 2000
TX tests
Def. value: GAUSs
Example See Specifying Measurement-Specific Settings
Characteristics Firmware version V1.00
CONFigure:GPRF:MEAS<i>:POWer:FILTer:GAUSs:BWIDth <Bandwidth>
Selects the bandwidth for a filter of Gaussian shape.
<Bandwidth> Range: 1 kHz| 3 kHz | 5 kHz | 10 kHz | 30 kHz | 50 kHz| 100
kHz| 300 kHz | 500 kHz | 1 MHz| 3 MHz | 5 MHz | 10 MHz
Def. value: 1 MHz
Unit: Hz
Example See Specifying Measurement-Specific Settings
Characteristics Firmware version V1.00
CONFigure:GPRF:MEAS<i>:POWer:FILTer:BANDpass:BWIDth <Bandwidth>
Selects the bandwidth for a bandpass filter.
<Bandwidth> Range: 1 kHz| 3 kHz | 5 kHz | 10 kHz | 30 kHz | 50 kHz| 100
kHz| 300 kHz | 500 kHz | 1 MHz| 3 MHz | 5 MHz | 10 MHz | 30
MHz | 40 MHz
Def. value: 300 kHz
Unit: Hz
Example See Specifying Measurement-Specific Settings
Characteristics Firmware version V1.00
7.4.3.6 Trigger Settings
The following commands define the trigger parameters.
