8.3.1.2 Specifying General Measurement Settings
FPRINT ************************************************************
FPRINT System-Reset
FPRINT ************************************************************
*RST;*OPC?
*CLS; *OPC?
FPRINT ************************************************************
FPRINT Define signal routing, perform RF and analyzer settings
FPRINT for a GSM900 uplink signal (channel 1) with a
FPRINT nominal power of 20 dBm and GMSK/8PSK modulation
FPRINT ************************************************************
ROUTe:GSM:MEASurement:RFSettings:CONNector RF1C
CONFigure:GSM:MEASurement:RFSettings:EATTenuation 2
CONFigure:GSM:MEASurement:RFSettings:ENPower 20
CONFigure:GSM:MEASurement:RFSettings:UMARgin 5
CONFigure:GSM:MEASurement:RFSettings:FREQuency 890.2E+6
WAITKEY >Signal routing and analyzer settings completed, press
"OK" to continue<
8.3.1.3 Specifying Measurement-Specific Settings
FPRINT ************************************************************
FPRINT Define statistic cycles and error handling
FRRINT (no stop when tolerances are exceeded, measure on exception)
FPRINT ************************************************************
CONFigure:GSM:MEASurement:MEValuation:SCOunt:PVTime 100
CONFigure:GSM:MEASurement:MEValuation:SCOunt:MODulation 10
CONFigure:GSM:MEASurement:MEValuation:SCOunt:SMODulation 10
CONFigure:GSM:MEASurement:MEValuation:SCOunt:SSWitching 10
CONFigure:GSM:MEASurement:MEValuation:SCONdition SLFail
CONFigure:GSM:MEASurement:MEValuation:MOEXception ON
FPRINT ************************************************************
FPRINT Use a power trigger to start the measurement
FPRINT Configure the instrument for a single-slot measurement
FPRINT in the active timeslot detected by the trigger system
FPRINT ************************************************************
CONFigure:GSM:MEASurement:MEValuation:TRIGger:SOURce POWer
CONFigure:GSM:MEASurement:MEValuation:TRIGger:SLOPe REDGe
