R&S
®
CMW 500 GSM Applications
GSM Command Reference
Operating Manual 1202.3986.32 – 03 256
<Sync State>, PEND: waiting for resource allocation, adjustment, hardware
switching ("pending")
ADJ: all necessary adjustments finished, measurement running
("adjusted")
INV: not applicable because <main_state>: OFF or RDY
("invalid")
<Resources State> QUE: measurement without resources, no results available
("queued")
ACT: resources allocated, acquisition of results in progress but
not complete ("active")
INV: not applicable because <main_state>: OFF or RDY
("invalid")
Example See Single Shot and Continuous Measurements
Characteristics Firmware version V1.00
SCPI: Query only
8.4.2.3 Enabling Results and Views
The following commands select the evaluated results and the displayed views.
CONFigure:GSM:MEAS<i>:MEValuation:RESult:PVTime
CONFigure:GSM:MEAS<i>:MEValuation:RESult:EVMagnitude
CONFigure:GSM:MEAS<i>:MEValuation:RESult:MERRor
CONFigure:GSM:MEAS<i>:MEValuation:RESult:PERRor
CONFigure:GSM:MEAS<i>:MEValuation:RESult:SMFRequency
CONFigure:GSM:MEAS<i>:MEValuation:RESult:SMTime
CONFigure:GSM:MEAS<i>:MEValuation:RESult:SSFRequency
CONFigure:GSM:MEAS<i>:MEValuation:RESult:SSTime
<Status>
Enables or disables the evaluation of results and shows or hides the views in the multi-
evaluation measurement. The last mnemonic denotes the view type: Power vs. Time,
Error Vector Magnitude, Magnitude Error, Phase Error, ACP Modulation Frequency,
ACP Modulation Time, ACP Switching Frequency, ACP Switching Time.
Results for disabled views
Use READ...? queries to retrieve results for disabled views; see
Retrieving results for
disabled views .
