R&S
®
CMW 500 GSM Applications
GSM Command Reference
Operating Manual 1202.3986.32 – 03 263
<Trigger Offset> Range: 0 to 7
Def. value: 0
Def. unit: (slots)
Example See Specifying Measurement-Specific Settings
Characteristics Firmware version V1.00
CONFigure:GSM:MEAS<i>:MEValuation:TRIGger:TOUT <Trigger Timeout>
Selects the maximum time that the R&S CMW 500 will wait for a trigger event before it
stops the measurement. This setting is not valid for free run measurements
(CONFigure:GSM:MEAS<i>:MEValuation:TRIGger:SOURce FRUN).
<Trigger Timeout> Range: 0 ms to 16777215 ms
Def. value: 1000 ms
Def. unit: ms
Example See Specifying Measurement-Specific Settings
Characteristics Firmware version V1.00
CONFigure:GSM:MEAS<i>:MEValuation:AMODe <Mode>
Selects the method that the R&S CMW 500 uses for frame synchronization.
<Mode> GAP: Gap
PATTern: Pattern
Def. value: PATTern
Example See Selecting Specific Burst Types
Characteristics Firmware version V1.00
CONFigure:GSM:MEAS<i>:MEValuation:GLENgth <Gap Length>
Defines the gap length as an integer number of slots. The gap length is used for frame
synchronization if the gap acquisition mode is active
(CONFigure:GSM:MEAS<i>:MEValuation:AMODe GAP).
<Gap Length> Range: 1 | 2 | 3
Def. value: 2
Def. unit: (slots)
Example See Selecting Specific Burst Types
Characteristics Firmware version V1.00
CONFigure:GSM:MEAS<i>:MEValuation:APATtern
<Pattern 0>, ..., <Pattern 7>
Defines the burst pattern that the R&S CMW 500 expects in the TDMA frames of the
received GSM signal. The pattern is used for frame synchronization if the pattern
