Rohde & Schwarz CMW 500 - Configure:gsm:meas<I>:Mevaluation:limit:epsk:smodulation:mpoint<Offset; Configure:gsm:meas<I>:Mevaluation:limit:epsk:smodulation:rpower

R&S
®
CMW 500 GSM Applications
GSM Command Reference
Operating Manual 1202.3986.32 – 03 280
<Status> ON: Enable limits for the given <offset>
OFF: Disable limits for the given <offset>
Def. value, <offset> = 1 to 11: ON
Def. value, <offset> = 12 to 20: OFF
Characteristics Firmware version V1.00
CONFigure:GSM:MEAS<i>:MEValuation:LIMit:EPSK:SMODulation:RPOWer
<Low Power>, <High Power>
Defines two reference power values for the modulation scheme 8PSK. These values
are relevant in the context of the next command.
<Low Power>, Low reference power value
Range: 0 dBm to 43 dBm
Def. value: 33 dBm
Def. unit: dBm
<High Power> High reference power value
Range: 0 dBm to 43 dBm
Def. value: 34 dBm
Def. unit: dBm
Characteristics Firmware version V1.00
CONFigure:GSM:MEAS<i>:MEValuation:LIMit:EPSK:SMODulation:MPOint<offset
>
<Low Power Limit>, <High Power Limit>, <Absolute Limit>, <Status>
Defines and activates a limit line for the modulation scheme 8PSK for a certain
frequency offset. The specified limits apply above the high power reference value and
below the low power reference value defined by the previous command. Between the
two reference power values the limits are determined by linear interpolation.
<offset>
Number of the frequency offset value. The offsets are defined by
the command
CONFigure:GSM:MEAS<i>:MEValuation:SMODulation:F
OFFsets
Range: 1 to 20
Def. value: 1
<Low Power Limit>, Relative power limit applicable below the low reference power
(see previous command).
Range: -120 dB to 31.5 dB
Def. value, <offset> = 1 to 4: 0.5 dB, -30 dB, -33 dB, -54 dB
Def. value, <offset> = 5 to 20: -60 dB
Def. unit: dB
