R&S
®
CMW 500 GSM Applications
GSM Command Reference
Operating Manual 1202.3986.32 – 03 285
Characteristics Firmware version V1.00
SCPI: Query only
For additional information concerning syntax elements and returned values refer to
Multi Evaluation Measurement Commands.
8.4.2.17 EVM Measurement Results (Single Values)
The following commands return the EVM results of the multi-evaluation measurement
for the "Measured Slot" (CONFigure:GSM:MEAS<i>:MEValuation:MSLots).
FETCh:GSM:MEAS<i>:MEValuation:EVMagnitude?
READ:GSM:MEAS<i>:MEValuation:EVMagnitude?
Returns the RMS and peak EVM values measured in the "Measured Slot". In addition
to the current value statistical values are returned (average, maximum, standard
deviation and 95th percentile).
Returned values
<Reliability>, Reliability indicator
<RMS Current>,
<RMS Average>,
<RMS Maximum>,
Range: 0 % to 100 %
Def. unit: %
<RMS Std Dev>, Range: 0 % to 50 %
Def. unit: %
<Peak Current>,
<Peak Average>,
<Peak Maximum>,
Range: 0 % to 100 %
Def. unit: %
<Peak Std Dev>, Range: 0 % to 50 %
Def. unit: %
<95th Percentile>, Range: 0 % to 100 %
Def. unit: %
Characteristics Firmware version V1.00
SCPI: Query only
For additional information concerning syntax elements and returned values refer to
Multi Evaluation Measurement Commands.
8.4.2.18 Magnitude Error Measurement Results (Trace)
The following commands return the magnitude error trace results of the multi-
evaluation measurement for the "measured slot"
(CONFigure:GSM:MEAS<i>:MEValuation:MSLots).
