R&S
®
CMW 500 WCDMA Applications
WCDMA Command Reference
Operating Manual 1202.3986.32 – 03 349
<Limit 3.84 MHz>, Absolute limit referenced to a 3.84 MHz filter
Range: –80 dBm to 33 dBm
Def. value: –48.5 dBm
Def. unit: dBm
Additional parameters: OFF | ON (disables the limit check |
enables the limit check using the previous/default limit values)
<Limit 1 MHz>, Absolute limit referenced to a 1MHz filter
Range: –80 dBm to 33 dBm
Def. value: –13 dBm
Def. unit: dBm
Additional parameters: OFF | ON (disables the limit check |
enables the limit check using the previous/default limit values)
<Limit 30 kHz> Absolute limit referenced to a 30 kHz filter
Range: –80 dBm to 33 dBm
Def. value: –15 dBm
Def. unit: dBm
Additional parameters: OFF | ON (disables the limit check |
enables the limit check using the previous/default limit values)
Example See Specifying Limits
Characteristics Firmware version V1.00
CONFigure:WCDMa:MEAS<i>:MEValuation:LIMit:EMASk:RELative
<Limit Point A>, <Limit Point B>, <Limit Point C>, <Limit Point D>, <Limit Point
E>, <Limit Point F>
Defines relative limits for the spectrum emission curves.
<Limit Point A>,
<Limit Point B>,
<Limit Point C>,
<Limit Point D>,
<Limit Point E>,
<Limit Point F>
Range: –90 dB to 0 dB
Def. values for points A to F [dB]:
-47.5, -47.5, -37.5, -33.5, -48.275, -33.725
Def. unit: dB
Additional parameters: OFF | ON (disables the limit check |
enables the limit check using the previous/default limit values)
Example See Specifying Limits
Characteristics Firmware version V1.00
9.4.2.9 EVM Measurement Results (Traces)
The following commands return the EVM trace results of the multi-evaluation
measurement.
FETCh:WCDMa:MEAS<i>:MEValuation:TRACe:EVMagnitude:RMS:CURRent?
