CMW 500 WCDMA Applications
WCDMA Command Reference
Operating Manual 1202.3986.32 – 03 356
FETCh:WCDMa:MEAS<i>:MEValuation:TRACe:PERRor:PEAK:SDEViation?
READ:WCDMa:MEAS<i>:MEValuation:TRACe:PERRor:PEAK:SDEViation?
Returns the standard deviation phase error trace values for up to 120 slots. Each
standard deviation is calculated from all "Current" peak values of a half slot or a full slot
measured since the start of the measurement. This trace can not be displayed at the
GUI.
Returned values
<Reliability>, Reliability indicator
<Std Dev 1>,
...,
<Std Dev 120/240>
Phase error standard deviation results: 120 values for a "full slot
measurement" and 240 values for a "half slot measurement"
Range: 0 deg to +90 deg
Def. unit: deg
Example See Performing Single Shot Measurements
Characteristics Firmware version V1.00
SCPI: Query only
For additional information concerning syntax elements and returned values refer to
Multi Evaluation Measurement Commands.
9.4.2.12 Spectrum Emission Measurement Results (Traces)
The following commands return the spectrum emission trace results of the multi-
evaluation measurement.
FETCh:WCDMa:MEAS<i>:MEValuation:TRACe:EMASk:MFLeft:CURRent?
FETCh:WCDMa:MEAS<i>:MEValuation:TRACe:EMASk:MFLeft:AVERage?
FETCh:WCDMa:MEAS<i>:MEValuation:TRACe:EMASk:MFLeft:MAXimum?
FETCh:WCDMa:MEAS<i>:MEValuation:TRACe:EMASk:MFRight:CURRent?
FETCh:WCDMa:MEAS<i>:MEValuation:TRACe:EMASk:MFRight:AVERage?
FETCh:WCDMa:MEAS<i>:MEValuation:TRACe:EMASk:MFRight:MAXimum?
READ:WCDMa:MEAS<i>:MEValuation:TRACe:EMASk:MFLeft:CURRent?
READ:WCDMa:MEAS<i>:MEValuation:TRACe:EMASk:MFLeft:AVERage?
READ:WCDMa:MEAS<i>:MEValuation:TRACe:EMASk:MFLeft:MAXimum?
READ:WCDMa:MEAS<i>:MEValuation:TRACe:EMASk:MFRight:CURRent?
READ:WCDMa:MEAS<i>:MEValuation:TRACe:EMASk:MFRight:AVERage?
READ:WCDMa:MEAS<i>:MEValuation:TRACe:EMASk:MFRight:MAXimum?
Returns the values of the spectrum emission 1 MHz traces. The left section and the
right section of each trace are retrieved by separate commands (dinstinguished by the
terms MFLeft and MFRight). The results of the current, average and maximum traces
can be retrieved.
