R&S
®
CMW 500 WCDMA Applications
WCDMA Command Reference
Operating Manual 1202.3986.32 – 03 360
<Margin AB>,
<Margin BC>,
<Margin CD>,
<Margin EF>,
<Margin FE>,
<Margin DC>,
<Margin CB>,
<Margin BA>,
Limit line margin values in the 8 limit line areas
Range: -100 dB to 0 dB
Def. unit: dB
<UE Power> User equipment power
Range: -100 dBm to +60 dBm
Def. unit: dBm
Example See Performing Single Shot Measurements
Characteristics Firmware version V1.00
SCPI: Query only
For additional information concerning syntax elements and returned values refer to
Multi Evaluation Measurement Commands.
9.4.2.15 Measurement Results (Single Values)
The following commands return the results of the multi-evaluation measurement,
measured in a selected slot
(CONFigure:WCDMa:MEAS<i>:MEValuation:SSCalar:MODulation).
FETCh:WCDMa:MEAS<i>:MEValuation:MODulation:CURRent?
FETCh:WCDMa:MEAS<i>:MEValuation:MODulation:MAXimum?
READ:WCDMa:MEAS<i>:MEValuation:MODulation:CURRent?
READ:WCDMa:MEAS<i>:MEValuation:MODulation:MAXimum?
Returns the current and minimum/maximum single value results.
Returned values
<Reliability>, Reliability indicator
<EVM RMS>,
<EVM Peak>,
Error vector magnitude RMS and peak value
Range: 0 % to 100 %
Def. unit: %
<Mag Err RMS>,
<Mag Err Peak>,
Magnitude error RMS and peak value
Range: -100 % to +100 %
Def. unit: %
<Phase Err RMS>,
<Phase Err Peak>,
Phase error RMS and peak value
Range: -180 deg to +180 deg
Def. unit: deg
