CMW 500 WiMAX Applications
WiMAX Command Reference
Operating Manual 1202.3986.32 – 03 399
permutation zone. The multi-evaluation measurement analyzes a burst which consists
of several sub-channels; refer to the Map of Bursts settings.
CONFigure:WIMax:MEAS<i>:MEValuation:ZDSNo <Segment No>
Specifies the segment number associated with the sub-channels. The total set of UL
sub-channels is grouped into three segments.
<Segment No> Range: 0 | 1| 2
Def. value: 0
Characteristics Firmware version V1.00
CONFigure:WIMax:MEAS<i>:MEValuation:ZLENgth <Zone Length>
Specifies the duration of the measured zone as an integer number of OFDMA symbols.
The R&S CMW 500 uses a fixed 18-symbol zone length.
<Zone Length> Range: 18
Def. value: 18 (no alternative setting)
Characteristics Firmware version V1.00
CONFigure:WIMax:MEAS<i>:MEValuation:PBASe <Perm Base>
Specifies the UL_PermBase parameter which defines the assignment of tiles to sub-
channels.
<Perm Base> Range: 0 to 69
Def. value: 0
Characteristics Firmware version V1.00
CONFigure:WIMax:MEAS<i>:MEValuation:NOBursts <No of Bursts>
Specifies the number of bursts within the measured UL permutation zone. The R&S
CMW 500 measures a single burst.
<No of Bursts> Range: 1 (no alternative selection)
Def. value: 1
Characteristics Firmware version V1.00
10.3.2.6 Map of Bursts
The following commands define the properties of the analyzed burst within the UL
PUSC permutation zone including the sub-channel and slot allocation.
