R&S
®
CMW 500 WiMAX Applications
WiMAX Command Reference
Operating Manual 1202.3986.32 – 03 406
Returned values
<Reliability>, Reliability indicator
<Crest Factor> Range: 0.0 dB to +100.0 dB
Def. unit: dB
Characteristics Firmware version V1.00
SCPI: Query only
For additional information concerning syntax elements and returned values refer to
Multi Evaluation Measurement Commands.
10.3.2.11 Measurement Results (Spectral Flatness)
The following commands return the spectral flatness results.
FETCh:WIMax:MEAS<i>:MEValuation:SFOupper:CURRent?
FETCh:WIMax:MEAS<i>:MEValuation:SFOupper:AVERage?
FETCh:WIMax:MEAS<i>:MEValuation:SFOupper:MAXimum?
FETCh:WIMax:MEAS<i>:MEValuation:SFOupper:MINimum?
READ:WIMax:MEAS<i>:MEValuation:SFOupper:CURRent?
READ:WIMax:MEAS<i>:MEValuation:SFOupper:AVERage?
READ:WIMax:MEAS<i>:MEValuation:SFOupper:MAXimum?
READ:WIMax:MEAS<i>:MEValuation:SFOupper:MINimum?
Returns the spectral flatness of the outer upper sub-carriers; see Table of Results. The
current, average, maximum and minimum values can be retrieved.
Returned values
<Reliability>, Reliability indicator
<Flatness Out Upp> Range: –100.0 dB to +100.0 dB
Def. unit: dB
Characteristics Firmware version V1.00
SCPI: Query only
For additional information concerning syntax elements and returned values refer to
Multi Evaluation Measurement Commands.
FETCh:WIMax:MEAS<i>:MEValuation:SFOLower:CURRent?
FETCh:WIMax:MEAS<i>:MEValuation:SFOLower:AVERage?
FETCh:WIMax:MEAS<i>:MEValuation:SFOLower:MAXimum?
FETCh:WIMax:MEAS<i>:MEValuation:SFOLower:MINimum?
READ:WIMax:MEAS<i>:MEValuation:SFOLower:CURRent?
READ:WIMax:MEAS<i>:MEValuation:SFOLower:AVERage?
