R&S
®
CMW 500 Getting Started
Sample Session
Operating Manual 1202.3986.32 – 03 31
To access the task bar:
Press the TASKS front panel key or "Ctrl + Tab" on your external
keyboard to open the task bar.
Use the mouse or the front panel hotkeys to click a particular task key.
2.2 Sample Session
The following measurement example consists of the following stages:
Generating an RF Signal
Measuring an RF Signal
Reset
To obtain predictable results it is recommendable to reset the R&S CMW 500. to a
definite state before you check out any of the measurement examples reported below.
Press the RESET front panel key to open the "Reset" dialog and select a "Preset".
2.2.1 Generating an RF Signal
Generators provide RF signals for test purposes.
All generators are controlled in an analogous manner.
2.2.1.1 GPRF Generator
The General Purpose RF (GPRF) generator provides an RF signal at constant
frequency or at a series of configurable frequencies and levels. It is also possible to
generate an RF signal that is modulated using a waveform file (ARB generator, option
R&S CMW-B110 A required). All RF signals are configured in a similar way.
To configure the GPRF generator for dual-tone signal at constant frequency,
1. Press the TASKS key on the front panel and select the "GPRF Generator" from
the task bar across the bottom of the display. See also Configuring the Task Bar.
The "General Purpose RF – Generator" dialog is opened.
