Remote control commands
R&S
®
RTE
1083User Manual 1326.1032.02 ─ 20
INT,8 | INT,16
Signed integer data with length 8 bit or 16 bit. It defines that
CHANnel<m>[:WAVeform<n>]:DATA[:VALues]? returns the
raw sample data of the ADC as integers. If format of the wave-
form data differs from the defined export format, the instrument
converts the data to the required length.
The result string has the same schema as the REAL format.
Fot INT,16 you can set the byte order using the FORMat:
BORDer command.
Data conversion is described in "Raw (ADC direct)"
on page 489.
For digital channel data, math and histogram data, INT formats
are not available.
EXPort:WAVeform:INCXvalues must be set OFF.
*RST:
ASCii
Example:
FORMat:DATA REAL,32
FORMat:DATA?
REAL,32
Usage: SCPI confirmed
FORMat:BORDer <ByteOrder>
Sets the endianess.
The command is only relevant for raw data export in high definition mode (16 bit word
length).
Parameters:
<ByteOrder> LSBFirst | MSBFirst
LSB first: little endian, least significant byte first
MSB first: big endian, most significant byte first
*RST: LSBFirst
Usage: Asynchronous command
FORMat:BPATtern <BitPatternFormat>
Sets the number format for remote bit pattern queries on serial protocols.
Parameters:
<BitPatternFormat> DEC | HEX | OCT | BIN | ASCII | ASCii | STRG
ASCII = ASCii
*RST: HEX
General remote settings
