Parameters:
<UpperLimit> Range: -100 to 100
Increment: 10E-6
*RST: 0
Usage: Asynchronous command
MEASurement<m>:SPECtrum:LCHeck<n>:LOWer:MARGin <LowerMargin>
MEASurement<m>:SPECtrum:LCHeck<n>:UPPer:MARGin <UpperMargin>
Define the lower and upper margins for the limit check, respectively. Margins are not as
strict as limits and must be within the valid value range. The valid range is defined
using the MEASurement<m>:SPECtrum:LCHeck<n>:VALid command.
Suffix:
<m>
.
1..10
See "Selection of the measurement: MEASurement<m>"
on page 1249.
<n> 1..15
Number of the spectrummeasurement type, see Table 18-7.
Parameters:
<UpperMargin> Range: -100 to 100
Increment: 10E-6
*RST: 0
Usage: Asynchronous command
18.12.6 Histograms
See also: Chapter 18.16.6, "Waveform histogram export to file", on page 1407
● Histogram display................................................................................................1277
● Histogram measurement.....................................................................................1283
18.12.6.1 Histogram display
LAYout:HISTogram:ADD............................................................................................... 1278
LAYout:HISTogram:SOURce......................................................................................... 1278
LAYout:HISTogram:MODE............................................................................................ 1279
LAYout:HISTogram:HORZ:MODE.................................................................................. 1279
LAYout:HISTogram:HORZ:ABSolute:STARt.................................................................... 1280
LAYout:HISTogram:HORZ:ABSolute:STOP.....................................................................1280
LAYout:HISTogram:HORZ:RELative:STARt.....................................................................1280
LAYout:HISTogram:HORZ:RELative:STOP..................................................................... 1280
LAYout:HISTogram:VERTical:MODE.............................................................................. 1281
LAYout:HISTogram:VERTical:ABSolute:STARt................................................................ 1281
LAYout:HISTogram:VERTical:ABSolute:STOP.................................................................1281
LAYout:HISTogram:VERTical:RELative:STARt.................................................................1282
