Remote control commands
R&S
®
RTE
1283User Manual 1326.1032.02 ─ 20
Usage: Setting only
Asynchronous command
18.12.6.2 Histogram measurement
This chapter lists commands to set up measurements on histograms.
See also: "Creating and reading histograms" on page 1058.
The following table lists the <MeasType> parameter values with a short description.
In addition, the suffixes <n> for limit check remote commands are listed.
For a detailed description, see Table 8-7.
Table 18-8: Histogram measurement types
<MeasType>
parameter value
(remote control)
Measurement
(manual opera-
tion)
Description/Result Suffix
<n>
WCOunt Waveform count Number of acquisitions (waveforms) the histogram
is based on
1
WSAMples Waveform samples Number of samples from the most recent acquisition
included in the current histogram
2
HSAMples Histogram samples Number of samples from all acquisitions included in
the current histogram
3
HPEak Histogram peak Maximum sample value in the histogram 4
PEAK Peak value Signal value at the histogram peak 5
UPEakvalue Upper peak value Signal value at the maximum sample value in the
upper half of the histogram
6
LPEakvalue Lower peak value Signal value at the maximum sample value in the
lower half of the histogram
7
HMAXimum Maximum Highest signal value with a probability > 0 8
HMINimum Minimum Lowest signal value with a probability > 0 9
MEDian Median Signal value for which half the samples lie above,
the other half below in the histogram
10
MAXMin Max - Min Range of signal values with a probability > 0 11
HMEan Mean Weighted arithmetic average of the histogram 12
HSTDdev σ (S-dev) Standard deviation of the sample numbers 13
M1STddev Mean ±σ Range between (mean value + standard deviation)
and (mean value - standard deviation)
14
M2STddev Mean ±2*σ Range between (mean value + 3 * standard devia-
tion) and (mean value - 2 * standard deviation)
15
M3STddev Mean ±3*σ Range between (mean value + 3 * standard devia-
tion) and (mean value - 2 * standard deviation)
16
Automatic measurements
