Slope
Sets the edge type for the trigger condition.
"Positive"
Selects the rising edge, that is a positive voltage change.
"Negative"
Selects the falling edge, that is a negative voltage change.
"Both"
Selects the rising as well as the falling edge. This option is not availa-
ble if the trigger source is the external trigger input.
Remote command:
TRIGger<m>:EDGE:SLOPe on page 1168
TRIGger<m>:ANEDge:SLOPe on page 1170
TRIGger<m>:SLEW:SLOPe on page 1181
Trigger level
Sets the voltage level for the trigger condition. You can also drag the trigger level
marker on the display (TA or TB on the right edge of the display). The range of the trig-
ger level is limited in a way so that always a hysteresis for stable trigger conditions is
available.
Remote command:
TRIGger<m>:LEVel<n>[:VALue] on page 1166
6.9 Acquisition info
Access: "Trigger" menu > "Acquisition Info"
Shows the current number of acquisitions that have been acquired. The count is shown
for a running acquisition cycle and as well for the last stopped acquisition cycle.
Remote command:
ACQuire:CURRent? on page 1210
