8.1.2 Using cursors
You can start cursor measurements by using the "Cursor" icon on the toolbar, or using
the [CURSOR] key. For detailed configuration, use the "Cursor" dialog box.
● Starting a simple cursor measurement................................................................. 324
● Configuring a cursor measurement.......................................................................325
● Configuring the cursor display...............................................................................326
● Saving measurement results to file.......................................................................326
8.1.2.1 Starting a simple cursor measurement
To display cursors using the toolbar
1. Tap the "Cursor" icon on the toolbar.
2. Tap the waveform that you want to measure. Alternatively, you can draw a rectan-
gle in the diagram to position the cursor lines.
The cursor lines appear and the cursor results are displayed in a table or result
box.
To display cursors using the [CURSOR] key
1. Select the waveform that you want to measure.
2. Press the [CURSOR] key.
The cursor lines appear and the cursor results are displayed in a table or result
box.
To disable one cursor measurement
► If the results are shown in a floating result box, or in a result icon: Close the result
box or icon.
► If the results are shown in a docked table:
a) Tap the "Delete" icon on the toolbar.
b) Tap a cursor line.
The cursor set and its measurement results are deleted.
To disable all cursor measurements
► If the results are shown in a docked table:
a) Tap the "Delete" icon on the toolbar.
b) Tap the results table.
All cursor sets and measurement results are deleted.
