Remote command:
BUS<m>:MILStd:MAXResponse:BITS on page 1607
BUS<m>:MILStd:MAXResponse:SELect on page 1607
TRIGger<m>:MILStd:MAXResponse:BITS on page 1616
TRIGger<m>:MILStd:MAXResponse:SELect on page 1617
13.9.2.2 Configuring MIL-STD-1553
For configuration assign the line to the input channel, set the threshold and the timing
conditions.
For details on configuration settings, see Chapter 13.9.2.1, "MIL-STD-1553 configura-
tion settings", on page 661.
1. Press the [PROTOCOL] key on the front panel.
2. Select the tab of the bus you want to set up, for example "SB1".
3. In the "Decode" tab, select the protocol: "MIL-STD-1553".
4. Optionally, you can enter a "Bus label" on the "Display" tab.
5. Tap the "Polarity" button, and select the waveform of the data line.
6. Set the logical thresholds.
7. If necessary, tap the "Min Gap" button to select it and set the minimum gap time.
8. If necessary, tap the "Max Response" button to select it and set the maximum
response time.
13.9.3 MIL-STD-1553 trigger
13.9.3.1 Trigger settings MIL-STD-1553
Access: [PROTOCOL] > "Trigger" tab > "Source = Serial Bus"
Make sure that:
●
In the [PROTOCOL] > "Decode" tab:
– The correct "Protocol" is selected.
– The data sources of the serial bus are channel signals.
●
In the "Trigger" > "Setup" tab:
– The trigger "Sequence" = "A only".
– The trigger "Source" = "Serial bus".
– The correct "Serial bus" is selected.
MIL-1553 (option R&S
RTE-K6)
