Remote control commands
R&S
®
RTE
1938User Manual 1326.1032.02 ─ 20
WGENerator<m>:VOLTage[:VPP] <Amplitude>
Sets the amplitude, peak to peak voltage, of the output waveform. This is defined as
the voltage difference between the maximum (WGENerator<m>:VOLTage:HIGH) and
the minimum (WGENerator<m>:VOLTage:LOW) voltage levels.
The value is set for the currently selected load (WGENerator<m>:OUTPut[:LOAD]).
If the load is changed, the value of the amplitude is adapted to this new setting.
Suffix:
<m>
.
1..2
Parameters:
<Amplitude> Range: 0.01 to 12
Increment: 0.1
*RST: 1
Default unit: V
WGENerator<m>:VOLTage:DCLevel
<DCLevel>
Sets the DC level of the generated DC signal.
Suffix:
<m>
.
1..2
Parameters:
<DCLevel> Range: -5.995 to 5.995
Increment: 0.1
*RST: 0
Default unit: V
WGENerator<m>:VOLTage:HIGH <High>
Sets the high signal level of the output waveform.
Suffix:
<m>
.
1..2
Parameters:
<High> Range: -5.99 to 6
Increment: 0.1
*RST: 0.5
Default unit: V
WGENerator<m>:VOLTage:INVersion <Inversion>
Enables inversion, which swaps the two poles of the waveform.
Suffix:
<m>
.
1..2
Waveform generator (option R&S RTE-B6)
