d) If you selected a user-defined constant, define its value:
● Press "Value" and enter the numeric value.
● Press "Decimal Point" to move the decimal point within the numeric value.
●
Press "Prefix" to define an SI-prefix to the unit. See also: "Prefix"
on page 108.
●
Press "Unit" to define the unit of the value. See also: "Unit" on page 109.
e) Press "Save" to store the user-defined constant.
7.
Press "Unit" to define the unit of the equation results. See also: "Unit" on page 102.
8. Optionally, press "Equation Label" to define a name for the equation. This label is
displayed on the "Equation" softkey and in the "Equation Set Editor".
To edit an equation set
1. Press "MATH > Edit Equations" to display the "Equation Set Editor".
2. Press "Equation" to select the first equation to be configured. This equation is
assigned to the first math waveform (MA1).
3. Configure the equation.
See: "To configure an equation" on page 99.
4. Repeat steps 3 and 4 to configure all 5 equations in the equation set.
5. Press "Back" to exit the editor and return to the main "Mathematics" menu.
6. For each equation MA1 to MA4, define whether it is to be displayed or not:
a) Press "Equation" to select the equation.
b) Press "Visible" to switch the display of the math waveform on or off.
7. Optionally, press "Eq. Set Label" to define a name for the equation set. This label is
displayed in the "Equation Set Editor".
7.1.3 Saving and Loading Equation Sets
If you want to keep math configurations for specific measurement purposes for later use,
you can save equations sets in the instrument or on external storage device.
To copy a stored equation sets to another storage device, use FILE > "Equation Sets".
For import/export procedure, see chapter 13.2.1.2, "Importing and Exporting Data",
on page 218.
To save the current equation set
1. Press MATH to display the "Mathematics" menu.
2. Press "Save".
3. Define the storage location using the "Storage" softkey, and the file name using the
"File name" softkey.
