Remote control commands
R&S
®
RTP
1162User Manual 1337.9952.02 ─ 12
22.7.2.3 Grid appearance
DISPlay:DIAGram:GRID............................................................................................... 1162
DISPlay:DIAGram:LABels............................................................................................. 1162
DISPlay:DIAGram:FINegrid........................................................................................... 1162
DISPlay:DIAGram:CROSshair....................................................................................... 1162
DISPlay:DIAGram:YFIXed.............................................................................................1163
DISPlay:DIAGram:XFIXed.............................................................................................1163
DISPlay:DIAGram:GRID <Show>
If enabled, a grid is displayed in the diagram area.
Parameters:
<Show> ON | OFF
Usage: Asynchronous command
DISPlay:DIAGram:LABels
<ShowLabels>
If enabled, labels mark values on the x- and y-axes in specified intervals in the dia-
gram.
Parameters:
<ShowLabels> ON | OFF
Usage: Asynchronous command
DISPlay:DIAGram:FINegrid <ShowFineScale>
If ON, the crosshair is displayed as a ruler with scale markers. If OFF, the crosshair is
shown as dashed lines.
Parameters:
<ShowFineScale> ON | OFF
Usage: Asynchronous command
DISPlay:DIAGram:CROSshair <Crosshair>
If selected, a crosshair is displayed in the diagram area. A crosshair allows you to
select a specific data point by its co-ordinates.
Parameters:
<Crosshair> ON | OFF
Usage: Asynchronous command
Instrument setup
