Remote control commands
R&S
®
RTP
1244User Manual 1337.9952.02 ─ 12
DIFFerential<m>:STATe <State>
Activates the differential signal. Two differential signals are available.
Suffix:
<m>
.
1..2
Differential signal
Parameters:
<State> ON | OFF
*RST: OFF
Usage: Asynchronous command
DIFFerential<m>:PSIGnal[:SELect] <Signal>
DIFFerential<m>:NSIGnal[:SELect] <Signal>
Select the analog input channel of the positive and negative signal.
Using the same input channel for both differential signals is not possible.
Suffix:
<m>
.
1..2
Differential signal
Parameters:
<Signal> C1W1 | C2W1 | C3W1 | C4W1
*RST: C1W1
Usage: Asynchronous command
DIFFerential<m>:AOUTput <Output>
DIFFerential<m>:BOUTput <Output>
Select the waveform that is the result of differential processing. 2 output waveforms per
digital signal can be defined.
The number of output waveforms depends on deembedding, see "Output: P, N, Differ-
ential, Common" on page 204.
If deembedding by software is active, use the DIFFerential:...:STATe com-
mands instead of AOUTput and BOUTput.
If realtime deembedding is active, only DIFFerential<m>:AOUTput is relevant,
because only one output waveform is available.
Suffix:
<m>
.
1..2
Differential signal
Parameters:
<Output> P | N | DIFF | COM
P | N
Positive or negative waveform.
Acquisition and setup
