Remote control commands
R&S
®
RTP
1321User Manual 1337.9952.02 ─ 12
<ZoomName> Name of the zoom diagram
Usage: Asynchronous command
LAYout:ZOOM:HORZ:ABSolute:SPAN <DiagramName>, <ZoomName>,<Span>
LAYout:ZOOM:HORZ:ABSolute:SPAN? <DiagramName>, <ZoomName>
Defines the width of the zoom area.
For numerical values, the input of a unit is not supported for this command.
Parameters:
<Span> Range: 0 to 100E+24
Increment: 0.01
*RST: 0.01
Parameters for setting and query:
<DiagramName> Name of the diagram on which the zoom area is based.
<ZoomName> Name of the zoom diagram
Usage: Asynchronous command
LAYout:ZOOM:HORZ:ABSolute:STARt <DiagGroupNme>,
<ZoomDiagramName>,<Start>
LAYout:ZOOM:HORZ:ABSolute:STARt? <DiagGroupNme>, <ZoomDiagramName>
Defines the lower limit of the zoom area on the x-axis.
For numerical values, the input of a unit is not supported for this command.
Parameters:
<Start> Range: -100E+24 to 100E+24
Increment: 0.01
*RST: 0
Parameters for setting and query:
<DiagGroupNme> Name of the diagram on which the zoom area is based.
<ZoomDiagramName>Name of the zoom diagram
Usage: Asynchronous command
LAYout:ZOOM:HORZ:ABSolute:STOP <DiagramName>, <ZoomName>,<Stop>
LAYout:ZOOM:HORZ:ABSolute:STOP? <DiagramName>, <ZoomName>
Defines the upper limit of the zoom area on the x-axis.
For numerical values, the input of a unit is not supported for this command.
Parameters:
<Stop> Range: -100E+24 to 100E+24
Increment: 0.01
*RST: 0.01
Waveform analysis
