Remote control commands
R&S
®
RTP
1324User Manual 1337.9952.02 ─ 12
Usage: Asynchronous command
LAYout:ZOOM:VERTical:ABSolute:POSition <DiagramName>,
<ZoomName>,<Position>
LAYout:ZOOM:VERTical:ABSolute:POSition? <DiagramName>, <ZoomName>
Defines the y-value of the centerpoint of the zoom area.
For numerical values, the input of a unit is not supported for this command.
Parameters:
<Position> Range: -100E+24 to 100E+24
Increment: 0.01
*RST: 0.01
Parameters for setting and query:
<DiagramName> Name of the diagram on which the zoom area is based.
<ZoomName> Name of the zoom diagram
Usage: Asynchronous command
LAYout:ZOOM:VERTical:ABSolute:SPAN <DiagramName>, <ZoomName>,<Span>
LAYout:ZOOM:VERTical:ABSolute:SPAN? <DiagramName>, <ZoomName>
Defines the height of the zoom area.
For numerical values, the input of a unit is not supported for this command.
Parameters:
<Span> Range: 0 to 100E+24
Increment: 0.01
*RST: 0.01
Parameters for setting and query:
<DiagramName> Name of the diagram on which the zoom area is based.
<ZoomName> Name of the zoom diagram
Usage: Asynchronous command
LAYout:ZOOM:VERTical:ABSolute:STARt <DiagGroupNme>,
<ZoomDiagramName>,<Start>
LAYout:ZOOM:VERTical:ABSolute:STARt? <DiagGroupNme>,
<ZoomDiagramName>
Defines the lower limit of the zoom area on the y-axis.
For numerical values, the input of a unit is not supported for this command.
Parameters:
<Start> Range: -100E+24 to 100E+24
Increment: 0.01
*RST: 0
Waveform analysis
