Remote control commands
R&S
®
RTP
1325User Manual 1337.9952.02 ─ 12
Parameters for setting and query:
<DiagGroupNme> Name of the diagram on which the zoom area is based.
<ZoomDiagramName>Name of the zoom diagram
Usage: Asynchronous command
LAYout:ZOOM:VERTical:ABSolute:STOP <DiagramName>, <ZoomName>,<Stop>
LAYout:ZOOM:VERTical:ABSolute:STOP? <DiagramName>, <ZoomName>
Defines the upper limit of the zoom area on the y-axis.
For numerical values, the input of a unit is not supported for this command.
Parameters:
<Stop> Range: -100E+24 to 100E+24
Increment: 0.01
*RST: 0.01
Parameters for setting and query:
<DiagramName> Name of the diagram on which the zoom area is based.
<ZoomName> Name of the zoom diagram
Usage: Asynchronous command
LAYout:ZOOM:VERTical:RELative:POSition <DiagramName>,
<ZoomName>,<RelPosi>
LAYout:ZOOM:VERTical:RELative:POSition? <DiagramName>, <ZoomName>
Defines the y-value of the centerpoint of the zoom area.
Parameters:
<RelPosi> Relative position of the centerpoint (y-value)
Range: 0 to 100
Increment: 0.1
*RST: 100
Default unit: %
Parameters for setting and query:
<DiagramName> Name of the diagram on which the zoom area is based.
<ZoomName> Name of the zoom diagram
Usage: Asynchronous command
LAYout:ZOOM:VERTical:RELative:SPAN <DiagramName>,
<ZoomName>,<RelativeSpan>
LAYout:ZOOM:VERTical:RELative:SPAN? <DiagramName>, <ZoomName>
Defines the height of the zoom area.
Waveform analysis
