Remote control commands
R&S
®
RTP
1392User Manual 1337.9952.02 ─ 12
<MeasType>
parameter value
(remote control)
Measurement
(manual opera-
tion)
Description/Result Suffix
<n>
SBWidth Bandwidth n dB down bandwidth; the samples to the left and
right of the peak value are analyzed until the n dB
threshold is exceeded; the frequencies at which the
threshold is exceeded define the limits of the
requested bandwidth
4
not used 5, 6
THD THD[dB] Total harmonic distortion in dB 7
THDPCT THD[%] Total harmonic distortion in % 8
THDA THD_a Is equivalent to THD. Requires option R&S RTP-
K37.
9
THDU THD_u Requires option R&S RTP-K37. 10
THDR THD_r Distortion factor. Requires option R&S RTP-K37. 11
PLISt Peak list List of frequency and peak power value pairs.
Requires option R&S RTP-K37.
12
HAR Harmonic search Returns the measured harmonics. For each har-
monic, the frequency and the value are listed. To get
the number of result pairs (= harmonics), use
MEASurement<m>:RESult:COUNt?.
13
THDF THD_f Root mean square of the sum of all amplitudes of
the harmonic waves in relation to the amplitude at
the fundamental frequency (first harmonic).
Requires option R&S RTP-K37.
14
SPAR Arithmetic for spec-
trum measure-
ments
Basic arithmetic calculations with measurement val-
ues and scalars.
15
MEASurement<m>:SPECtrum:CPOWer:BANDwidth....................................................... 1393
MEASurement<m>:SPECtrum:OBANdwidth................................................................... 1393
MEASurement<m>:SPECtrum:CPOWer:CFRequency.....................................................1393
MEASurement<m>:SPECtrum:NDBDown...................................................................... 1394
MEASurement<m>:SPECtrum:PEXCursion....................................................................1394
MEASurement<m>:SPECtrum:ATHReshold................................................................... 1394
MEASurement<m>:SPECtrum:RESult<n>:COUNt...........................................................1395
MEASurement<m>:SPECtrum:RESult<n>:MODE........................................................... 1395
MEASurement<m>:RESult:MAXCount........................................................................... 1395
MEASurement<m>:RESult:SHFRequency......................................................................1396
MEASurement<m>:RESult:SHLabels.............................................................................1396
MEASurement<m>:SPECtrum:LCHeck<n>:VALid........................................................... 1397
MEASurement<m>:SPECtrum:LCHeck<n>:LOWer:LIMit................................................. 1397
MEASurement<m>:SPECtrum:LCHeck<n>:UPPer:LIMit.................................................. 1397
MEASurement<m>:SPECtrum:LCHeck<n>:LOWer:MARGin............................................ 1398
MEASurement<m>:SPECtrum:LCHeck<n>:UPPer:MARGin.............................................1398
Automatic measurements
