Remote control commands
R&S
®
RTP
1501User Manual 1337.9952.02 ─ 12
SEARch:TRIGger:PATTern:A[:ENABle] <Searchname>, <State>
SEARch:TRIGger:PATTern:A[:ENABle]? <Searchname>
SEARch:TRIGger:PATTern:B[:ENABle] <Searchname>, <State>
SEARch:TRIGger:PATTern:B[:ENABle]? <Searchname>
SEARch:TRIGger:PATTern:C[:ENABle] <Searchname>, <State>
SEARch:TRIGger:PATTern:C[:ENABle]? <Searchname>
SEARch:TRIGger:PATTern:D[:ENABle] <Searchname>, <State>
SEARch:TRIGger:PATTern:D[:ENABle]? <Searchname>
Enables the channel to be considered in the pattern search. The trigger source chan-
nel is selected by default.
●
A[:ENABle]: CH1
●
B[:ENABle]: CH2
●
C[:ENABle]: CH3
●
D[:ENABle]: CH4
Digital channels are not available.
Parameters:
<State> ON | OFF
Parameters for setting and query:
<Searchname> String with name of the search
Usage: Asynchronous command
SEARch:TRIGger:PATTern:A:LOGic <Searchname>, <Operator>
SEARch:TRIGger:PATTern:A:LOGic? <Searchname>
SEARch:TRIGger:PATTern:B:LOGic <Searchname>, <Operator>
SEARch:TRIGger:PATTern:B:LOGic? <Searchname>
SEARch:TRIGger:PATTern:C:LOGic <Searchname>, <Operator>
SEARch:TRIGger:PATTern:C:LOGic? <Searchname>
SEARch:TRIGger:PATTern:D:LOGic <Searchname>, <Operator>
SEARch:TRIGger:PATTern:D:LOGic? <Searchname>
Defines the logic for the indicated channel:
●
A: CH1
●
B: CH2
●
C: CH3
●
D: CH4
Parameters:
<Operator> DIRect | HIGH | NOT | LOW
DIRect
Input value remains unchanged
NOT
Input value is inverted
Parameters for setting and query:
<Searchname> String with the name of the search
Search
