Remote control commands
R&S
®
RTP
1558User Manual 1337.9952.02 ─ 12
Parameters:
<RWBitAddress> READ | WRITe | EITHer
EITHer
Transfer direction is not relevant.
*RST: EITHer
Usage: Asynchronous command
TRIGger<m>:I2C:ADNack <AddressNack>
Triggers if the address acknowledge bit is missing - no slave recognizes the address.
Parameters:
<AddressNack> ON | OFF
*RST: ON
Usage: Asynchronous command
TRIGger<m>:I2C:DWNack
<DataWriteNack>
Triggers if a date acknowledge bit is missing - the addressed slave does not accept the
data.
Parameters:
<DataWriteNack> ON | OFF
*RST: ON
Usage: Asynchronous command
TRIGger<m>:I2C:DRNack <DataReadNack>
Triggers on the end of the read process when the master reads data from the slave.
This Nack is sent according to the protocol definition, it is not an error.
Parameters:
<DataReadNack> ON | OFF
*RST: ON
Usage: Asynchronous command
TRIGger<m>:I2C:AMODe <AddressType>
Sets the address length. The setting affects the address input with TRIGger<m>:I2C:
ADDRess and TRIGger<m>:I2C:ADDTo.
Parameters:
<AddressType> BIT7 | BIT7_RW | BIT10 | ANY
BIT7
Enter the 7 address bits. Only available if BUS<m>:I2C:RWBit
SEParate is set.
