Remote control commands
R&S
®
RTP
1728User Manual 1337.9952.02 ─ 12
Alternatively, digital channels can be used if MSO option R&S RTP-B1 is installed. Dig-
ital and analog channels cannot be used at the same time.
For triggering on a serial bus, analog or digital channel sources are required.
Suffix:
<m>
.
1..4
Parameters:
<SourceData> C1W1 | C2W1 | C3W1 | C4W1 | M1 | M2 | M3 | M4 | M5 | M6 |
M7 | M8 | R1 | R2 | R3 | R4
See Chapter 22.4.2, "Waveform parameter", on page 1145
*RST: C1W1
BUS<m>:ETHernet:POLarity
<Polarity>
Defines the polarity of the data signal. This setting is only available in 10BASE-T.
Suffix:
<m>
.
1..4
Parameters:
<Polarity> NORMal | INVert
NORMal
Normal (non-inverted) data signal polarity
INVert
Inverted data signal polarity
*RST: NORMal
BUS<m>:ETHernet:THReshold:HIGH <ThresholdUpper>
Sets the upper threshold value for the signal digitization. If the signal value is higher
than the this threshold, the signal state is considered high.
Suffix:
<m>
.
1..4
Parameters:
<ThresholdUpper> Range: 0 to 10
Increment: 0.01
*RST: 0.5
Default unit: V
BUS<m>:ETHernet:THReshold:LOW <ThresholdLower>
Sets the lower threshold value for the signal digitization. If the signal value is below this
threshold, the signal state is considered low.
Suffix:
<m>
.
1..4
Protocols
