Remote control commands
R&S
®
RTP
1852User Manual 1337.9952.02 ─ 12
TRIGger<m>:DPHY:ESCMode:CONDition <Format>
Set the condition for the escape mode. You can define an exact value or a value range
Parameters:
<Format> EQUal | NEQual | LTHan | LETHan | GTHan | GETHan |
INRange | OORange
EQUal | NEQual | LTHan | LETHan | GTHan | GETHan
Equal, Not equal, Less than, Less or equal than, Greater Than,
Greater or equal than. These conditions require one pattern to
be set with the corresponding TRIGger<m>:DPHY:ESCMode:
MIN command.
INRange | OORange
In range/Out of range: set the minimum and maximum value of
the range with TRIGger<m>:DPHY:ESCMode:MIN and
TRIGger<m>:DPHY:ESCMode:MAX.
*RST:
EQUal
TRIGger<m>:DPHY:ESCMode:MAX <LPEscapeModeMax>
Sets the the end value of an escape mode range if TRIGger<m>:DPHY:ESCMode:
CONDition is set to INRange or OORange.
Parameters:
<LPEscapeModeMax>Numeric or string pattern, see Chapter 22.4.6, "Bit pattern
parameter", on page 1148. The string parameter accepts the bit
value X (don't care).
TRIGger<m>:DPHY:ESCMode:MIN <LPEscapeModeMin>
Specifies a escape mode bit pattern, or sets the the start value of a pattern range.
Parameters:
<LPEscapeModeMin>Numeric or string pattern, see Chapter 22.4.6, "Bit pattern
parameter", on page 1148. The string parameter accepts the bit
value X (don't care).
TRIGger<m>:DPHY:ESDTa:CONDition <Format>
Set the condition for the escape mode data value. You can define an exact value or a
value range.
Parameters:
<Format> OFF | ANY | EQUal | NEQual | LTHan | LETHan | GTHan |
GETHan | INRange | OORange
