Rohde & Schwarz RTP Series - Page 1855

Remote control commands
R&S
®
RTP
1855User Manual 1337.9952.02 ─ 12
Parameters:
<HSWordCountMax> Numeric or string pattern, see Chapter 22.4.6, "Bit pattern
parameter", on page 1148. The string parameter accepts the bit
value X (don't care).
TRIGger<m>:DPHY:WCOunt:MIN <HSWordCountMin>
Specifies a word bit pattern, or sets the the start value of a pattern range.
Parameters:
<HSWordCountMin> Numeric or string pattern, see Chapter 22.4.6, "Bit pattern
parameter", on page 1148. The string parameter accepts the bit
value X (don't care).
22.17.14.3
D-PHY decode results
To show the results on the screen, use the following commands:
●
BUS<m>:RESult on page 1549
BUS<m>:DPHY:RESult:FCOunt?.................................................................................. 1855
BUS<m>:DPHY:RESult:FRAMe<n>:CS?........................................................................1855
BUS<m>:DPHY:RESult:FRAMe<n>:DATA?.................................................................... 1856
BUS<m>:DPHY:RESult:FRAMe<n>:DTName?............................................................... 1856
BUS<m>:DPHY:RESult:FRAMe<n>:DTYPe?..................................................................1857
BUS<m>:DPHY:RESult:FRAMe<n>:ECC?..................................................................... 1857
BUS<m>:DPHY:RESult:FRAMe<n>:PACKet<o>:IDX?..................................................... 1857
BUS<m>:DPHY:RESult:FRAMe<n>:PACKet<o>:VALue?.................................................1858
BUS<m>:DPHY:RESult:FRAMe<n>:STARt?...................................................................1858
BUS<m>:DPHY:RESult:FRAMe<n>:STATe?...................................................................1858
BUS<m>:DPHY:RESult:FRAMe<n>:STOP?................................................................... 1859
BUS<m>:DPHY:RESult:FRAMe<n>:TYPE?....................................................................1859
BUS<m>:DPHY:RESult:FRAMe<n>:NUMPackets?......................................................... 1860
BUS<m>:DPHY:RESult:FRAMe<n>:VCHannel?............................................................. 1860
BUS<m>:DPHY:RESult:FCOunt?
Returns the number of decoded frames for the selected serial bus.
Suffix:
<m>
.
1..4
Return values:
<Count> Range: 0 to 100000
Increment: 1
*RST: 0
Usage: Query only
BUS<m>:DPHY:RESult:FRAMe<n>:CS?
Returns the checksum of the specified frame.
Protocols
