Remote control commands
R&S
®
RTP
2288User Manual 1337.9952.02 ─ 12
CDR:SOFTware<m>:ESBRate:SOURce <BitrateSource>
Selects the source of the data stream, which is analized to recover the clock.
Suffix:
<m>
.
1..2
Number of the software CDR setup
Parameters:
<BitrateSource> C1W1 | C2W1 | C3W1 | C4W1 | R1 | R2 | R3 | R4
Usage: Asynchronous command
CDR:SOFTware<m>:ESBRate:BREStimate
Estimates the bit rate once, for the current acquisition.
Suffix:
<m>
.
1..2
Number of the software CDR setup
Usage: Event
Asynchronous command
CDR:SOFTware<m>:ESBRate:CONTinuous <BitrateEstimation>
Enables ongoing correction of the bit rate.
Suffix:
<m>
.
1..2
Number of the software CDR setup
Parameters:
<BitrateEstimation> ON | OFF
*RST: OFF
Usage: Asynchronous command
CDR:SOFTware<m>:BITRate <Bitrate>
Sets the quiescent frequency of the PLL. It corresponds to the data rate of the data
stream from which the clock is to be recovered.
Suffix:
<m>
.
1..2
Number of the software CDR setup
Parameters:
<Bitrate> Range: 100 to max {5 Gbps, <available instrument band-
width}
Increment: 10
*RST: 1E+9
Default unit: bps
Jitter analysis and clock data recovery
