Remote control commands
R&S
®
RTP
2291User Manual 1337.9952.02 ─ 12
Parameters:
<PLLRelBw> Range: 10 to 5000
Increment: 1
*RST: 1667
Usage: Asynchronous command
CDR:SOFTware<m>:PLL:DAMPing <DampingFactor>
Sets the damping factor, which is only relevant for second order PLL.
Suffix:
<m>
.
1..2
Number of the software CDR setup
Parameters:
<DampingFactor> Range: 0.5 to 1
Increment: 0.01
*RST: 0.7
Usage: Asynchronous command
CDR:SOFTware<m>:REVLockpll <ReverseLockPll>
Enables the reverese lock PLL algorithm. The signal is locked on the first edge.
Suffix:
<m>
.
1..2
Parameters:
<ReverseLockPll> ON | OFF
*RST: ON
Usage: Asynchronous command
CDR:SOFTware<m>:SAMTime <UntIntvlOffs>
Sets a sampling time for the clock signal, an offset for the clock edge in relation to the
bit start. The clock edge sets the beginning of the unit interval. The sampling time is a
number between 0 and 1. Value 0 sets the clock edge to the beginning of the bit
period; value 0.5 sets the clock edge to the middle of the bit period.
Suffix:
<m>
.
1..2
Parameters:
<UntIntvlOffs> Range: 0 to 1
Increment: 0.01
*RST: 0.5
Default unit: UI
Usage: Asynchronous command
Jitter analysis and clock data recovery
