Remote control commands
R&S
®
RTP
2297User Manual 1337.9952.02 ─ 12
DEEMbedding<m>:COMPonent<n>:TYPE <Type>
Sets the type of the indicated component. The first component is always DUT, the last
component is PROBe or INPut.
Suffix:
<m>
.
1..4
Selects the channel that is configured for deembedding.
<n> 1..n
Index of the component in the measurement setup. The DUT
has index 1, the probe has index n.
Parameters:
<Type> PROBe | FIXTure | CABLe | DUT | ADAPter | INPut | OTHer |
RTZA10 | RTZA16 | RTZA17 | PP | PC
RTZA10 | RTZA16 | RTZA17
SMA adapters and cable offered by Rohde & Schwarz
PP | PC
Proven probe, proven cable
*RST: CABLe
Usage: Asynchronous command
DEEMbedding<m>:COMPonent<n>:NAME <Name>
Sets a name for the indicated component that helps you identifying it.
Suffix:
<m>
.
1..4
Selects the channel that is configured for deembedding.
<n> 1..n
Index of the component in the measurement setup. The DUT
has index 1, the probe has index n.
Parameters:
<Name> String parameter, name of the component
Usage: Asynchronous command
DEEMbedding<m>:COMPonent<n>:PCOunt?
Returns the number of all ports of the selected component (input ports and output
ports).
The number of ports depends on the attached probe. If a modular probe R&S RT-ZM
or differential probe R&S RT-ZD is used, the number of ports is 4. Otherwise, 2 ports
are available.
Suffix:
<m>
.
1..4
Selects the channel that is configured for deembedding.
Deembedding (Option R&S RTP-K121/-K122)
