Triggers
R&S
®
RTP
233User Manual 1337.9952.02 ─ 12
Most video signals have an output impedance of 75 Ω. The channel inputs of the
R&S RTP have an input impedance of 50 Ω. Make sure to provide the adequate
matching to ensure amplitude fidelity.
Once the trigger is set correctly, you can use cursor and automatic measurements to
perform amplitude and timing measurements.
Trigger types
