Protocol analysis
R&S
®
RTP
845User Manual 1337.9952.02 ─ 12
Table 13-36: Content of the Decode results table
Column Description
Frame Frame number
State Overall state of the frame, for example "OK" or "Incomplete"
Start Start time of the frame
Frame Type Type of the frame
Info Specific frame information, for example result of the Link Speed Measurement =
5.0 Gb/s, or content of the Data Packet Payload
Enable "Details" in the decode table to display a more detailed analysis of the selected
frame.
Table 13-37: Content of the Details frame table
Column Description
State Overall state of the field
Start Start time of the field
Stop Stop time of the field
Type Type (name) of field
Numeric value The numeric value of the field
Formatted Formatted content of the field, for example HPSTART "F7" = end packet framing
(EPF)
Remote commands
Remote control commands for retrieving decode results are described in Chap-
ter 22.17.20, "USB 3.1 (option R&S RTP-K61/K62)", on page 2044.
Remote command:
●
BUS<m>:USBThree:RESult:FCOunt? on page 2067
●
BUS<m>:USBThree:RESult:FRAMe<n>:INFO? on page 2067
●
BUS<m>:USBThree:RESult:FRAMe<n>:TYPE? on page 2067
●
BUS<m>:USBThree:RESult:FRAMe<n>:STATe? on page 2068
●
BUS<m>:USBThree:RESult:FRAMe<n>:STARt? on page 2068
●
BUS<m>:USBThree:RESult:FRAMe<n>:STOP? on page 2069
●
BUS<m>:USBThree:RESult:FRAMe<n>:FLD<o>:TYPE? on page 2069
●
BUS<m>:USBThree:RESult:FRAMe<n>:FLD<o>:STATus? on page 2069
●
BUS<m>:USBThree:RESult:FRAMe<n>:FLD<o>:STARt? on page 2070
●
BUS<m>:USBThree:RESult:FRAMe<n>:FLD<o>:STOP? on page 2070
●
BUS<m>:USBThree:RESult:FRAMe<n>:FLD<o>:VAL? on page 2070
●
BUS<m>:USBThree:RESult:FRAMe<n>:FLD<o>:FVAL? on page 2071
USB 3.1 (option R&S
RTP-K61/K62)
