Remote control commands
R&S
®
RTP
1451User Manual 1337.9952.02 ─ 12
Parameters:
<Mode> ABS | REL
*RST: ABS
Usage: Asynchronous command
CALCulate:MATH<m>:FFT:GATE:RELative:STARt <RelativeStart>
Defines the starting value for the gate in percent.
Suffix:
<m>
.
1..8
math waveform
Parameters:
<RelativeStart> Range: 0 to 100
Increment: 0.1
*RST: 0
Default unit: %
Usage: Asynchronous command
CALCulate:MATH<m>:FFT:GATE:RELative:STOP <RelativeStop>
Defines the end value for the gate in percent.
Suffix:
<m>
.
1..8
math waveform
Parameters:
<RelativeStop> Range: 0 to 100
Increment: 0.1
*RST: 100
Default unit: %
Usage: Asynchronous command
CALCulate:MATH<m>:FFT:GATE:ZCOupling <ZoomCoupling>
If enabled, the gate area is defined identically to the zoom area for the zoom diagram.
Suffix:
<m>
.
1..8
math waveform
Parameters:
<ZoomCoupling> ON | OFF
*RST: OFF
Usage: Asynchronous command
Spectrum analysis
