Remote control commands
R&S
®
RTP
1629User Manual 1337.9952.02 ─ 12
Suffix:
<m>
.
1..4
Selects the serial bus.
Return values:
<Count> Total number of decoded frames.
Range: 0 to 100000
Increment: 1
*RST: 0
Usage: Query only
BUS<m>:CAN:FDATa:FRAMe<n>:STANdard?
Returns the CAN standard.
The setting is available in CAN FD option R&S RTP-K9.
Suffix:
<m>
.
1..4
Selects the serial bus.
<n> *
The frame suffix is irrelevant.
Return values:
<Standard> CAN | CANFd
*RST: CAN
Usage: Query only
BUS<m>:CAN:FRAMe<n>:STATus?
Returns the overall state of the selected frame.
Suffix:
<m>
.
1..4
Selects the serial bus.
<n> *
Selects the frame.
Return values:
<FrameState> OK | FORM | BTST | CRC | CRCD | NOACk | ACKD | EOFD |
CAERror | FCERor | INSufficient | SERRror | SFERror |
SCERror | SAERror | SCAE | SCFE
OK: the frame is valid.
FORM: Fixed-bit form error
BTST: Bit stuffing error occured.
CRC: Cyclic redundancy check failed.
CRCD: Wrong CRC delimiter occured.
NOACK: Acknowlegde is missing.
ACKD: Wrong ACK delimiter occured.
Protocols
