Remote control commands
R&S
®
RTP
1908User Manual 1337.9952.02 ─ 12
SEARch:TRIGger:MPHY:DATA:IMAX <SearchName>,<DataIndexMax>
SEARch:TRIGger:MPHY:DATA:IMAX? <SearchName>
Sets the end value of the index range if SEARch:TRIGger:MPHY:DATA:
ICONdition is set to INRange or RANge.
Parameters:
<DataIndexMax> Range: 1 to 0
Increment: 1
*RST: 0
Parameters for setting and query:
<SearchName>
SEARch:TRIGger:MPHY:FSNumber:CONDition <SearchName>,<FSNOperator>
SEARch:TRIGger:MPHY:FSNumber:CONDition? <SearchName>
Sets the condition for FSN. You can define an exact value or a value range.
Parameters:
<FSNOperator> EQUal | NEQual | LTHan | LETHan | GTHan | GETHan |
INRange | OORange
EQUal | NEQual | LTHan | LETHan | GTHan | GETHan
Equal, Not equal, Less than, Less or equal than, Greater Than,
Greater or equal than. These conditions require one data pattern
to be set with the corresponding SEARch:TRIGger:MPHY:
FSNumber:MIN command.
INRange | OORange
In range/Out of range: set the minimum and maximum value of
the range with SEARch:TRIGger:MPHY:FSNumber:MIN and
SEARch:TRIGger:MPHY:FSNumber:MAX.
*RST:
EQUal
Parameters for setting and query:
<SearchName>
SEARch:TRIGger:MPHY:FSNumber:MIN <SearchName>,<FSNMin>
SEARch:TRIGger:MPHY:FSNumber:MIN? <SearchName>
Specifies the FSN bit pattern, or sets the start value of a pattern range.
Parameters:
<FSNMin> Numeric or string pattern, see Chapter 22.4.6, "Bit pattern
parameter", on page 1148. The string parameter accepts the bit
value X (don't care).
Parameters for setting and query:
<SearchName>
